The Syvecs Nissan Patrol Y62 Plug-In ECU delivers a new level of engine and vehicle control in a fully integrated, plug-and-play solution for 2017+ VK56DD models. Designed as a direct replacement for the factory ECU, it retains full OEM functionality while unlocking advanced calibration, transmission and performance strategies.

Engineered for both high-performance street and forced induction applications, the system provides motorsport-level control over engine behaviour, boost, traction and safety systems, all within a platform that remains intuitive for professional tuners and experienced end users.


Key Features

• Complete control of engine, transmission and torque management strategies
• Full VVEL control with optimised transmission behaviour and faster shifting
• Flex fuel capability with adaptive tuning for varying fuel types
• Support for turbo and supercharger applications with advanced boost control
• Adjustable launch control and rolling anti-lag strategies
• Advanced traction control using individual wheel speed and lateral G inputs
• Individual cylinder knock control for maximum engine protection
• Comprehensive engine safety strategies including oil pressure, temperature and fuel system monitoring
• Anti-theft and valet modes for added security and control
• Live tuning via high-speed Ethernet with onboard data logging up to 1000Hz
• Map switching and feature control via OEM steering wheel buttons


Specifications

Compatibility

Direct plug-in replacement for Nissan Patrol Y62 VK56DD (2017+)
Motorsport-grade ECU with OEM-style fitment

Outputs

8 x Direct Injection Injector Outputs
2 x Direct Injection Pump Outputs
4 x Ignition Outputs (TTL / IGBT)
8 x Low-Side Port Injector / PWM Outputs
6 x Low-Side PWM Outputs

Inputs

14 x frequency inputs:

4 x ADC voltage inputs
4 x thermistor inputs
2 x knock inputs
2 x wideband lambda inputs (NTK, Bosch LSU, or Denso AF, optional at time of order)
2 x EGT thermocouple inputs

Comms

3 x CAN buses (with CAN FD support)
1 x LIN
1 x RS232
1 x Ethernet for PC communications and data transfer
1 x USB PC communication interface for direct injection adjustment and custom CAN messaging


Pricing starts at $8,800

Please contact us for current price
