Syvecs X20 Lite Expander

The Syvecs X20 Expander is a high-performance I/O module designed to seamlessly extend the input and output capability of modern engine control systems. With the use of CAN controllers, the X20 communicates with MoTeC devices to behave as a slave for it, offering the I/O compliment to its master device.


Key Features

• 12 x sequential injector control with closed-loop fueling via onboard lambda or OEM ECU
• Flexible fuel and boost control using internal strategies or OEM ECU targets via CAN
• Dual lambda and knock control with feedback and protection to OEM ECU
• Dual wastegate control with internal or OEM-based targeting
• Built-in traction control with boost and torque management integration
• Flex fuel capability with adaptive control of fueling and boost
• Integration with MHD and Ecutek for expanded control strategies
• Nitrous and water/methanol injection control with full safety strategies
• Advanced safety features including lean protection and configurable limp modes
• High-speed USB datalogging (up to 4000Hz) and live tuning via SCAL (USB-C)
• OBD2 integration for access to OEM sensor data
• Advanced CAN / CANFD communication including bridging and custom messaging
• Optional FlexRay support for newer vehicle platforms
• External drive-by-wire control and crank/cam signal strategy support for advanced applications


Specifications

Hardware

150 x 150mm
IP67 Sealed in Automotive Spec -40c to 125c
2 x 34 way Superseal 1.0 connectors
6 to 26V input voltage range
Ignition Switch Logic with high current supply

Outputs

8 x Low Side Outputs (12Amp Peak (100ms) 6Amp Continuous)

Inputs

12 x Flexible Inputs supporting frequency, Sent, thermistor, bipolar
4 x ADC Voltage inputs
2 x NTK Lambda Inputs

Interfaces

USB For Updates and Configuration
2 x CAN 2.0B interface for communication with other controllers or logging systems
1 x Kline Interface


Pricing starts at $1,900

Please contact us for current price
