Syvecs S12 ECU

The S12 is Syvecs top of the range engine control unit. Designed to withstand some of the toughest of condition and still provide enough I/O to run a V12 engine fully sequentially for a life time.


Key Features

• Advanced processor architecture delivering precise engine position tracking and high-speed control strategies
• Extensive I/O capacity supporting complex multi-cylinder engines including V12 sequential configurations
• Flexible output configuration for ignition, injection, PWM and full-bridge control applications
• Supports advanced engine management functions including fuel, ignition, VVT, drive-by-wire and boost control
• Fully programmable CAN bus architecture with multi-channel communication capability
• Integrated knock control, wideband lambda support and temperature monitoring for accurate engine protection
• Comprehensive safety strategies with configurable limits and limp mode functionality
• High-speed Ethernet communication for rapid calibration, data transfer and analysis
• Large onboard data logging memory with detailed time-stamped recording
• Designed for demanding environments with robust automotive-grade construction and connector design
• Suitable for both standalone and integrated systems across high-performance road and motorsport builds


Specifications

Hardware

178 x 160 x 45 mm
Cased in a sealed aluminium billet unit
3 x waterproof connectors
Operating Temperature -25 to +95 C

Outputs

12 x Ignition Coil outputs – IGBT(Coil Direct) or TTL (ignitor)
24 x Fuel injector outputs
8 x PWM Outputs
3 x full bridges also configurable as 6 half bridges or 6 PWMs
Up to 20A output per Full Bridge (DbW & HDP-5)

Inputs

28 x General Purpose Inputs
4 x Knock Inputs
2 x NTK wide band Lambada interfaces
2 x K-type thermocouple interfaces

Communications

3 x Can 2.0B
Rs232 Serial Interface
100 Mhz Full Duplex Ethernet For Connection To PC For Programming And Data Download
Up to 128MB flash logging memory
Twin split automotive connector totalling 121 pins
